Kiln Tail Flue Gas Chamber Infrared Temperature Measurement System

1. Suitable for all kinds of kiln tail smoke room and kiln tail decomposing furnace. It can constantly monitor the temperature accurately.

Don't contact with measured object, without abrasion, free maintenance.

2. Measure temperature with high accuracy and fast speed.

3. Special wavelength, prevent the interference of the smoke.

4. Laconic structure, easy to mounting.

5. Use special high temperature resistant material, with high strength and corrosion resistant.

6. Laser collimation, accurate positioning.

7. Regular clean crust automatically, keep the temperature accuracy.

8. Use high- temperature rodless cylinder, with good reliability.

9. In the central control room, can control the equipment to entry and exit.

10. Without maintenance, save a lot of production time and manpower.

11. Three years warranty and has the advantages of being cheap.

Model:LM-CS2000

WhatsApp Now

Kiln Tail Flue Gas Chamber Infrared Temperature Measurement System

infrared temperature measurement system for kiln flue Parameter

Technical parameters	1. Temperature resolution: 1℃ 2. Distance coefficient: 150:1 3. Temperature Range: 0℃～1300℃ 4. Response time: 100ms 5. Spectral response: 5.14μm 6. Precision: 1.0% measured value (℃) 7. Repeatability: 0.5%measured value (℃) 8. Emissivity: 0.1～1.00 9. Power supply: 24VDC±25% 10. Export: 4MA～20MA/500ω 11. Output insulation: 500V 12. Environment temperature: -20℃～+75℃ 13. Environment humidity:＜90%
Compressed air	1. Air pipe port: G1/4" 2. Work pressure :0.2MPa～0.8MPa 3. Maximum moment: 15 (nm) 4. Maximum load: 300 (n) 5. Minimum flow:0.3 m³/min
Working condition temperature	1. Environment temperature: -20℃～75℃ 2. Environment humidity: ＜90% 3. Smoke room temperature:＜1400℃
Dimension	1. Automatically exit device:Φ115 (diameter) 1560 (length) (unit:mm) 2. Control box: 500700200mm (WH*D) 3. 4MA-20MA output connect with DSC 4. Installation diagram (see figure) 5. Open pore requirement (see figure)

FAQ

Q1: How does this infrared temperature measurement system handle smoke interference in the kiln environment?

A: The system is specifically engineered to overcome visibility issues in harsh industrial settings. It utilizes a special spectral response wavelength (5.14μm) that effectively prevents interference from smoke and dust. This allows the infrared temperature measurement system to provide accurate, non-contact temperature monitoring in the kiln tail flue gas chamber and decomposing furnace, ensuring data reliability even in heavy smoke conditions.

Q2: Is the system maintenance-free, and how is it controlled?

A: Yes, the system is designed to save production time and manpower. It features an automatic crust cleaning function that regularly cleans the lens to maintain temperature accuracy. Furthermore, the equipment uses a high-temperature resistant rodless cylinder and can be remotely controlled for entry and exit directly from the central control room, eliminating the need for manual intervention in high-heat areas.

Q3: What is the measuring range and warranty coverage for this system?

A: The system offers a wide measuring range of 0°C to 1300°C with a fast response time of 100ms and high precision (1.0%). In terms of after-sales support, this model comes with a three-year warranty, offering superior cost-effectiveness and long-term reliability compared to standard market options. It is built with special high-strength, corrosion-resistant materials to withstand the extreme environment.
